SMC Cylinder Replacement Parts – CXSM & CXSJM Series
Keep your pneumatic systems running smoothly with these precision-compatible replacement parts for SMC dual-rod slide cylinders in the CXSM and CXSJM series. Designed to fit a wide range of bore sizes — 6, 10, 15, 20, 25, and 32 mm — and stroke lengths from 10 to 75 mm, these parts are an essential maintenance staple for industrial automation, manufacturing equipment, and pneumatic assembly lines.
Key Features
- Wide Compatibility: Fits SMC CXSJM and CXSM6, CXSM10, CXSM15, CXSM20, CXSM25, and CXSM32 series cylinders across multiple stroke lengths (10, 15, 20, 25, 30, 40, 45, 50, and 75 mm).
- Durable Plastic Construction: Made from high-quality plastic engineered for reliable performance in pneumatic applications.
- Drop-In Fit: Designed to match OEM specifications for straightforward installation with no modification required.
- Minimizes Downtime: Stocking these parts ensures quick turnaround during scheduled maintenance or unexpected equipment stops.
- Versatile Use: Ideal for automation engineers, maintenance technicians, and facilities teams managing pneumatic cylinder inventories.
Specifications
| Compatible Series | SMC CXSJM, CXSM6, CXSM10, CXSM15, CXSM20, CXSM25, CXSM32 |
| Stroke Lengths | 10, 15, 20, 25, 30, 40, 45, 50, 75 mm |
| Material | Plastic |
| Country of Origin | Made in Mainland China |
Why Choose These Replacement Parts?
Pneumatic cylinder maintenance is critical to efficient production lines. Having the correct replacement components on hand reduces machine downtime and keeps operations moving. These parts are sourced to match the dimensional tolerances of genuine SMC dual-rod cylinders, making them a practical choice for technicians managing high-volume pneumatic systems.
For more information on pneumatic safety standards and best practices, visit the OSHA Control of Hazardous Energy (Lockout/Tagout) resource page.
Related Products You May Like
Learn more: Pneumatics
Frequently Asked Questions
Q: Which SMC cylinder models are these replacement parts compatible with?
A: These parts are compatible with the SMC CXSJM and CXSM dual-rod slide cylinder series, including bore sizes 6, 10, 15, 20, 25, and 32 mm, with stroke lengths ranging from 10 to 75 mm (10, 15, 20, 25, 30, 40, 45, 50, and 75 mm).
Q: What material are these SMC cylinder parts made from?
A: These replacement parts are constructed from durable plastic, engineered to meet the dimensional requirements of SMC CXSM and CXSJM series cylinders for dependable performance in pneumatic systems.
Q: Are these direct drop-in replacements, or do they require modification?
A: These parts are designed to match OEM specifications for the listed SMC cylinder series, allowing for straightforward installation without the need for additional machining or modification in most standard applications.
Q: Where are these parts manufactured?
A: These SMC cylinder replacement parts are made in Mainland China.
