Self-Healing Three-Phase Shunt Capacitor 440V–480V 30kvar

Self-Healing Low Voltage Three-Phase Shunt Capacitor – 440V / 450V / 480V, 30kvar

Upgrade your electrical power system with this professional-grade Self-Healing Low Voltage Shunt Capacitor. Designed for three-phase reactive power compensation and harmonic filtering, this 30kvar fixed capacitor is built to improve power factor, reduce energy losses, and stabilize voltage across industrial and commercial installations. Compatible with 440V, 450V, and 480V systems.

Key Features

• Self-Healing Technology: Metallized film construction allows the capacitor to automatically recover from minor dielectric breakdowns, extending service life and ensuring continuous operation.
• Three-Phase Reactive Power Compensation: Effectively compensates reactive power in industrial power grids, improving power factor and reducing utility demand charges.
• Harmonic Filtering Capability: Helps suppress harmonics in the power network, protecting sensitive equipment and improving overall power quality.
• Wide Voltage Compatibility: Rated for 440V, 450V, and 480V systems — suitable for a broad range of international and domestic industrial applications.
• 30kvar Reactive Power Rating: High-capacity output makes this ideal for medium to large industrial loads.
• Fixed Capacitor Design: Simple, reliable, and easy to integrate into existing power factor correction panels and switchboards.
• Durable Stainless Steel Housing: The robust stainless steel enclosure offers excellent protection against mechanical impact, moisture, and environmental contaminants.
• No Hazardous Chemicals: Contains no high-concern substances, making it safer to handle and dispose of responsibly.

Specifications

Typical Applications

• Industrial power factor correction panels
• Commercial electrical switchboards
• Motor drive systems and large inductive load installations
• Harmonic filtering networks
• Energy management and demand reduction systems

Why Choose a Self-Healing Capacitor?

Self-healing capacitors use a metallized film dielectric that vaporizes and clears fault points automatically, rather than failing permanently as older designs do. This means longer operational life, fewer replacements, and improved system reliability — a smart investment for any power quality improvement project.

For guidance on electrical safety standards and power factor correction best practices, refer to the OSHA Electrical Safety Guidelines.

Related Products

• 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
• 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler

Frequently Asked Questions

Q: What does a self-healing shunt capacitor do in a three-phase power system?

A: A self-healing shunt capacitor compensates for reactive power in a three-phase electrical system, improving the power factor and reducing energy losses. The self-healing property means that if a small dielectric fault occurs in the metallized film, it automatically clears itself without permanent damage, ensuring continued and reliable operation.

Q: Is this capacitor compatible with both 440V and 480V electrical systems?

A: Yes. This capacitor is rated for 440V, 450V, and 480V systems, making it versatile for use across a wide range of industrial and commercial electrical installations, including those in different countries with varying standard voltages.

Q: What size installation is this 30kvar capacitor best suited for?

A: At 30kvar, this capacitor is well-suited for medium to large industrial facilities, commercial buildings, or manufacturing plants with significant inductive loads such as motors, transformers, and variable frequency drives where reactive power compensation is required.

Q: Does this capacitor require special mounting or wiring?

A: This is a fixed capacitor designed for integration into standard power factor correction panels or switchboards. Installation should always be performed by a qualified electrician following local electrical codes and safety standards.
