NE555 Delay Timer Relay Module 5V/12V – 0–10S Adjustable Switch

NE555 Delay Timer Relay Switch Module – Adjustable 0–10 Second Delay

Take precise control of your electronics with the NE555 Delay Timer Relay Switch Module. Built around the legendary NE555 timer IC, this compact module delivers a reliable, fully adjustable delay of 0 to 10 seconds — perfect for car dashcam power sequencing, automation projects, pulse generation, and industrial control circuits. Runs on both 5V and 12V DC, making it compatible with a huge range of setups.

Made in Mainland China.

Key Features

• Adjustable Delay Time (0–10 Seconds): Set the exact delay your application requires via the onboard potentiometer. No external equipment needed.
• Expandable Delay Range: Swap out the potentiometer or increase the value of capacitor C1 to extend the delay well beyond the default 10-second range. Delay formula: T = 1.1RC.
• Dual Voltage Support: Operates on DC 5V or DC 12V, covering most hobby, automotive, and industrial use cases.
• Power Indicator LED: An onboard LED confirms that the module is live and powered — no guesswork needed during setup or troubleshooting.
• Relay Activation Indicator LED: A second LED lights up the moment the relay engages, giving you instant visual feedback on relay status.
• High-Load Relay Output: The built-in relay can switch up to AC 220V / 10A — capable of controlling devices up to 2000W.
• Relay Current Protection: Onboard protection circuitry safeguards the relay from damaging current spikes.
• Monostable (One-Shot) Operation: On power-up, the relay activates after the set delay and latches — ideal for "delayed start" and "power-on sequencing" applications.

Specifications

What's in the Box

• 1 × NE555 Delay Timer Relay Switch Module

Common Applications

• Car dashcam / driving recorder delayed power-on
• DIY home automation delay switching
• Industrial power sequencing and interlock circuits
• Pulse generation and duty-cycle experiments
• Arduino / microcontroller peripheral trigger delays
