High-Performance IGBT Power Modules – MPFP40R12EBF, MPFP25R12EBF, SGM35PA12A8TFD, SGM25PA12A8TFD
These industrial-grade IGBT (Insulated Gate Bipolar Transistor) power modules are engineered for demanding switching and power conversion applications. Whether you're building motor drives, inverters, UPS systems, or industrial automation equipment, these modules deliver reliable performance with efficient energy handling at 1200V class ratings.
Compatible Part Numbers
- MPFP40R12EBF
- MPFP25R12EBF
- SGM35PA12A8TFD
- SGM25PA12A8TFD
Key Features
- 1200V Voltage Class: Suitable for high-voltage power electronics applications including three-phase inverters and motor drives.
- High Current Ratings: Available in multiple current variants (25A–40A) to match your system's load requirements.
- Low Switching Losses: Advanced IGBT chip technology minimizes energy loss during high-frequency switching cycles, improving overall system efficiency.
- Robust Construction: Designed for industrial environments with excellent thermal performance and mechanical durability.
- Drop-In Compatibility: Cross-compatible part numbers allow easy sourcing and replacement across various OEM designs.
- No High-Concern Chemicals: Manufactured without restricted or high-concern chemical substances.
- Non-Electrified Package: Safe handling in standard ESD-protected environments.
Typical Applications
- Variable frequency drives (VFDs) and motor speed controllers
- Solar inverters and renewable energy converters
- Uninterruptible power supplies (UPS)
- Industrial automation and servo drives
- Welding equipment and power supplies
Specifications Overview
| Parameter | Detail |
|---|---|
| Part Numbers | MPFP40R12EBF, MPFP25R12EBF, SGM35PA12A8TFD, SGM25PA12A8TFD |
| Voltage Class | 1200V |
| Current Range | 25A – 40A |
| Device Type | IGBT Power Module |
| High-Concern Chemicals | None |
| Country of Origin | Made in Mainland China |
Related Products You May Need
- 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
- 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler
External Reference
For guidance on power electronics safety standards and best practices, refer to the OSHA Electrical Safety Standards to ensure proper handling and installation of high-voltage components.
Frequently Asked Questions
Q: What are the MPFP40R12EBF and SGM35PA12A8TFD modules used for?
A: These IGBT power modules are designed for high-voltage switching applications such as motor drives, solar inverters, UPS systems, and industrial automation equipment. They operate at a 1200V class rating and are available in current ratings of 25A to 40A.
Q: Are these part numbers cross-compatible with each other?
A: Yes. The MPFP40R12EBF, MPFP25R12EBF, SGM35PA12A8TFD, and SGM25PA12A8TFD are functionally similar IGBT modules in the same 1200V class family, making them convenient cross-reference replacements depending on the current rating required by your application.
Q: What is the country of origin for these IGBT modules?
A: These modules are made in Mainland China and are manufactured to meet standard industrial power electronics requirements.
Q: Do these modules contain any restricted or high-concern chemicals?
A: No. These IGBT power modules are manufactured without any high-concern or restricted chemical substances, ensuring compliance with common industrial safety standards.
