M23 17-Pin Circular Connector – M623 Straight Plug or Socket

M23 M623 17-Pin Circular Connector – Straight Type, Single Unit

This M23 / M623 Straight-Type Circular Connector offers a reliable, precision-engineered connection solution for industrial automation, robotics, servo drives, and sensor wiring systems. Available in both internal thread (female) and external thread (male) configurations, this single-unit connector is built to handle demanding environments with confidence.

Constructed from high-grade stainless steel, the M23 17-pin connector delivers exceptional mechanical durability and corrosion resistance — ideal for industrial machinery, CNC equipment, and field-installed control systems. The straight-type profile ensures a clean, compact installation wherever panel space is at a premium.

Key Features

• Standard M23 / M623 Form Factor – Fully compatible with M23 industry-standard specifications
• 17-Pin Configuration – High pin count supports complex signal and power wiring in a single connector
• Straight-Type Design – Compact inline profile for space-efficient panel and cable installations
• Available as Plug or Socket – Choose internal thread (female) or external thread (male) to match your application
• Stainless Steel Construction – Robust, corrosion-resistant housing for long-term reliability
• Industrial-Grade Performance – Suitable for automation, servo, robotic, and instrumentation applications
• Sold as Single Unit – Order the exact quantity and configuration you need

Specifications

Typical Applications

• Industrial automation and PLC wiring
• Servo motor and drive signal connections
• Robotics and motion control systems
• Sensor and encoder cabling
• CNC machinery and factory floor equipment

For guidance on industrial connector standards and safe wiring practices, visit OSHA Electrical Safety Standards.

Related Products You May Need

• 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
• 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler

Frequently Asked Questions

Q: What is the difference between the M23 internal thread and external thread connector?

A: The internal thread (female) connector features threads on the inside of the coupling nut, while the external thread (male) version has threads on the outer housing. Both are standard M23 / M623 configurations — choose the type that mates with your existing panel socket or cable connector.

Q: Is this M23 17-pin connector compatible with standard M23 servo and encoder cables?

A: Yes. This connector follows the standard M23 / M623 specification and is designed to be compatible with industry-standard M23 servo, encoder, and automation cables used across major industrial platforms.

Q: What industries commonly use M23 circular connectors?

A: M23 circular connectors are widely used in industrial automation, robotics, CNC machinery, motion control systems, servo drives, and sensor/encoder installations — anywhere a robust, multi-pin circular connection is required.

Q: Is this connector sold as a single unit or in a pack?

A: This listing is for a single connector unit. Please add the required quantity to your cart based on your installation needs.
