LSP5208 1024 PPR Photoelectric Rotary Encoder | Automation Part

LSP5208-001G1024BZ1-5-24F Photoelectric Rotary Encoder

Upgrade your automation setup with this precision Photoelectric Rotary Encoder, compatible with the LSP5208-001G1024BZ1-5-24F series. Designed for industrial automation equipment, this encoder delivers reliable position and speed feedback with 1024 pulses per revolution — ideal for motion control, CNC machinery, robotics, and a wide range of factory automation systems.

Key Features

• Model: LSP5208-001G1024BZ1-5-24F
• Resolution: 1024 PPR (Pulses Per Revolution) for high-accuracy position sensing
• Type: Photoelectric (optical) rotary encoder — non-contact sensing for long service life
• Voltage: 5–24V wide input voltage range for versatile compatibility
• Output: Incremental signal output suitable for PLCs, servo drives, and motion controllers
• Material: Durable plastic housing for lightweight, corrosion-resistant performance
• Application: Industrial automation, CNC equipment, conveyor systems, robotics, and more

Why Choose This Rotary Encoder?

Photoelectric rotary encoders use an optical disc and light-emitting sensors to generate precise electronic pulses as the shaft rotates. With 1024 pulses per revolution, this encoder provides the resolution needed for demanding automation and motion-control applications. Its broad 5–24V operating range makes it easy to integrate into existing control panels and PLC systems without additional signal conditioning.

Specifications at a Glance

Compatible Applications

• CNC milling and turning machines
• Industrial servo and stepper motor systems
• Conveyor belt position tracking
• Robotic arm joint feedback
• Printing and packaging machinery
• General factory automation equipment

For more information on encoder technology and industrial automation safety standards, visit the NIST Intelligent Systems & Robotics Division.

Frequently Asked Questions

Q: What does 1024 PPR mean on this photoelectric rotary encoder?

A: PPR stands for Pulses Per Revolution. A 1024 PPR encoder generates 1024 electrical pulses for every full rotation of the shaft. This high resolution makes it suitable for precise position control and speed measurement in automation and CNC equipment.

Q: What voltage range does the LSP5208-001G1024BZ1-5-24F encoder support?

A: This photoelectric rotary encoder supports a wide supply voltage range of 5V to 24V DC, making it compatible with most industrial PLCs, servo drives, and motion controllers without needing additional power conditioning.

Q: What type of output signal does this incremental encoder produce?

A: This encoder produces an incremental output signal (typically A/B phase quadrature pulses), which is the standard format accepted by most PLCs, servo amplifiers, and motion control systems used in industrial automation.

Q: Is this encoder suitable for outdoor or harsh environments?

A: This encoder features a plastic housing suitable for standard indoor industrial environments. For harsh outdoor or high-vibration environments, please check the specific IP rating and mechanical specifications before installation.
