Hollow Shaft Incremental Encoder – IHA8030-002J Series

Upgrade your motion control and automation systems with this precision Hollow Shaft Incremental Encoder compatible with the IHA8030-002J-600BZ2-5-24F model. Available in multiple pulse-per-revolution (PPR) configurations — 360, 1000, 1024, and 2000 PPR — this encoder delivers accurate rotational position feedback for a wide range of industrial and DIY applications.

Built with a durable plastic housing and engineered for reliable performance, this hollow shaft encoder is ideal for CNC machines, servo motors, conveyor systems, robotics, and other precision motion control setups. Its hollow shaft design allows for direct shaft mounting, eliminating the need for couplings and reducing installation complexity.

Key Features

• Multiple PPR Options: 360, 1000, 1024, and 2000 pulses per revolution for versatile application compatibility
• Hollow Shaft Design: Direct mount to motor or drive shaft for simplified, secure installation
• Incremental Output: Clean, reliable pulse output for position and speed feedback
• Durable Construction: Plastic body built to withstand typical industrial operating environments
• Wide Compatibility: Compatible with IHA8030-002J-600BZ2-5-24F and related encoder series
• Compact Form Factor: Easy to integrate into existing equipment with minimal footprint

Specifications

• Model: IHA8030-002J-600BZ2-5-24F (Parts/Replacement)
• Shaft Type: Hollow Shaft
• Encoder Type: Incremental
• PPR Options: 360 / 1000 / 1024 / 2000
• Material: Plastic
• Country of Origin: Made in Mainland China

Applications

• CNC machinery and milling systems
• Servo and stepper motor feedback
• Conveyor belt speed monitoring
• Robotics and automation equipment
• Printing and packaging machinery

For guidance on rotary encoders and their use in industrial automation, visit the NIST Intelligent Systems Division for standards and technical resources.

Related Products You May Like

• "1% Better Every Day" Motivational Canvas Wall Art Print
• "Everything Is Figureoutable" Sage Green Quote Canvas Wall Art

Frequently Asked Questions

Q: What PPR (pulses per revolution) options are available for this hollow shaft encoder?

A: This encoder is available in four PPR configurations: 360, 1000, 1024, and 2000 pulses per revolution. Choose the resolution that best matches your application's precision requirements — higher PPR values provide finer positional resolution.

Q: What is the advantage of a hollow shaft encoder over a solid shaft encoder?

A: A hollow shaft encoder mounts directly onto an existing motor or drive shaft, eliminating the need for additional couplings or adapters. This simplifies installation, reduces mechanical play, and saves space in tight assemblies, making it ideal for retrofits and compact automation setups.

Q: Is this encoder compatible with my CNC or servo motor system?

A: This encoder is designed as a compatible replacement part for the IHA8030-002J-600BZ2-5-24F series and works with a broad range of CNC, servo, and stepper motor systems that accept standard incremental encoder signals. Please verify shaft diameter and output signal type before ordering to ensure compatibility.

Q: What type of output signal does this encoder produce?

A: This is an incremental encoder that generates pulse-based output signals (typically A/B quadrature channels) used for measuring rotational speed and relative position. It does not retain absolute position on power cycle — a reference or home position routine is recommended at startup.
