DC Micro Gear Motor – 6V / 12V / 24V | High Torque, Low Speed
Power your automation projects with this compact and reliable DC Micro Gear Motor, available in 6V, 12V, and 24V configurations. Engineered with a permanent magnet construction and precision gear reduction, this motor delivers impressive torque output (up to 2Nm) at controlled low speeds — making it ideal for robotics, DIY automation, smart home devices, conveyors, dispensers, and more.
With a 32mm frame, flange mounting design, and a wide RPM range (10–1800 RPM depending on configuration), this motor fits seamlessly into space-constrained builds without sacrificing power. The IE2 efficiency rating ensures energy-conscious performance for continuous-duty applications.
Key Features
- Multi-Voltage Options: Available in DC 6V, 12V, and 24V rated inputs
- High Torque Output: Up to 2Nm torque for demanding low-speed drive tasks
- Compact 32mm Frame: Fits into tight enclosures and compact assemblies
- Permanent Magnet Construction: Stable, consistent magnetic field for smooth operation
- Flange Mounting: Easy integration into panels, frames, and housings
- Wide Speed Range: 10–1800 RPM across configurations (50–60 RPM low-speed variants available)
- IE2 Motor Efficiency: Energy-efficient for extended run-time applications
- Continuous Current Rating: 0.4A for reliable sustained operation
- No High-Concern Chemicals: Clean, safe materials
Specifications
| Voltage Options | DC 6V / 12V / 24V |
| Power Rating | 5W / 10W |
| Torque | Up to 2Nm (1Nm / 1.5Nm / 2Nm variants) |
| Speed Range | 10 – 1800 RPM (model dependent) |
| Frame Size | 32mm |
| Mounting Type | Flange Mounting |
| Construction | Permanent Magnet Type |
| Continuous Current | 0.4A |
| Motor Efficiency | IE2 |
| Model | HT-S-0068 |
| Country of Origin | Made in Mainland China |
Ideal Applications
- Robotics and automation systems
- Smart home actuators and motorized blinds
- Conveyor belts and dispensing machines
- DIY electronics and prototyping projects
- Arduino / Raspberry Pi motor control builds
- Medical and laboratory automated equipment
Related Products You May Like
- 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
- 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler
For guidance on electrical motor safety and standards, visit the U.S. Occupational Safety and Health Administration (OSHA) – Electrical Safety resource.
Frequently Asked Questions
Q: What voltages does this DC micro gear motor support?
A: This micro gear motor is available in DC 6V, 12V, and 24V variants, making it compatible with a wide range of power supplies and battery configurations commonly used in robotics, automation, and DIY electronics projects.
Q: What is the torque and speed output of this gear motor?
A: Depending on the selected model, torque ranges from 1Nm to 2Nm, with speeds spanning approximately 10 to 1800 RPM. Low-speed variants (50–60 RPM) are available for high-torque applications.
Q: How is this motor mounted in a system?
A: This gear motor uses a flange mounting design with a compact 32mm frame, allowing straightforward integration into panels, enclosures, and mechanical assemblies for both prototype and production builds.
Q: Is this motor suitable for continuous operation?
A: Yes. The motor is rated for continuous operation at 0.4A with IE2 efficiency, making it well-suited for sustained-duty automation tasks where reliable, long-running performance is required.
