BEG-561-440-130 Time-Delay Relay Module – 440V AC, 0.02s, 3.0/1.5A
The BEG-561-440-130 Time-Delay Relay (Part No. 13052798 / 13169183) is a precision-engineered control component designed for industrial and commercial electrical systems. Rated at 440V AC with a rapid 0.02-second delay time and dual current rating of 3.0/1.5A, this relay delivers reliable, repeatable switching performance in demanding environments.
Key Features
- Voltage Rating: 440V~ (AC)
- Delay Time: 0.02 seconds – ultra-fast response for precise timing applications
- Current Rating: 3.0A / 1.5A dual-channel capability
- Part Numbers: BEG-561-440-130 | 13052798 | 13169183
- Compact, panel-mount-ready design for easy integration into control cabinets
- Robust construction for long service life in industrial settings
- Made in Mainland China
Typical Applications
- Motor control circuits and starter panels
- Industrial automation and PLC auxiliary circuits
- HVAC and building management systems
- Electrical switchgear and control panels
Technical Specifications
| Parameter | Value |
|---|---|
| Model | BEG-561-440-130 |
| Part No. | 13052798 / 13169183 |
| Supply Voltage | 440V AC (~) |
| Delay Time | 0.02 seconds |
| Current Rating | 3.0A / 1.5A |
| Origin | Mainland China |
Related Products You May Need
- 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
- 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler
For guidance on safe installation of relay and timing components in electrical systems, refer to OSHA Electrical Safety Standards.
Frequently Asked Questions
Q: What voltage does the BEG-561-440-130 relay operate at?
A: This time-delay relay is rated for 440V AC operation, making it suitable for industrial three-phase electrical systems and high-voltage control circuits.
Q: What does the 3.0/1.5A dual current rating mean?
A: The dual current rating (3.0A / 1.5A) indicates the relay's switching capacity under different load or contact configurations — 3.0A for one contact configuration and 1.5A for the other. Always match the relay to your circuit's actual load requirements.
Q: Is this relay compatible with standard DIN-rail or panel-mount enclosures?
A: The BEG-561-440-130 is designed as a compact control component suited for integration into standard industrial control panels and enclosures. Verify dimensional compatibility with your specific enclosure before installation.
Q: What are the part numbers for cross-referencing this relay?
A: This relay can be cross-referenced by the following part numbers: BEG-561-440-130, 13052798, and 13169183.
