12/24V DC Frequency Compressor Driver Module 101N2156/101N2154

12/24V DC Direct Frequency Compressor Driver Module (101N2156 / 101N2154)

Power your portable refrigeration or cooling projects with this precision-engineered DC variable frequency compressor driver module. Compatible with both 12V and 24V DC power supplies, this compact controller board is designed to efficiently drive direct-drive frequency compressors — making it an ideal solution for DIY refrigerators, camping coolers, marine units, solar-powered fridges, and off-grid cooling systems.

Whether you're building a custom cooling enclosure or replacing a faulty driver in an existing system, this module delivers reliable, consistent performance with minimal setup required.

Key Features

• Dual Voltage Compatibility: Supports both 12V and 24V DC input — versatile for a wide range of applications
• Two Models Available: 101N2156 and 101N2154 — choose the exact variant that fits your compressor system
• Direct Frequency Drive: Smooth variable-speed control for efficient compressor operation and reduced power consumption
• Compact Module Design: Easy to integrate into custom builds, replacements, or OEM configurations
• Broad Application Range: Suitable for portable fridges, RV refrigeration, solar coolers, and marine cooling units
• Electrical DIY Compatible: Designed for use in electrical DIY and custom electronics projects

Specifications

Ideal For

• DIY portable refrigerator builds
• Solar-powered off-grid cooling units
• RV, camper van, and marine refrigeration systems
• Replacement driver boards for existing compressor units
• Electronics and electrical engineering projects

Related Products You May Like

• 1-Channel Relay Module DC 3.3V–24V Optocoupler for Arduino
• 1-Channel SCR Solid State Relay Module DC3-24V 40A Optocoupler
• 0.25mm 1000-Turn Precision Copper Inductor Coil for DIY Circuits

For more information on electrical safety standards for electronic components and driver modules, visit the U.S. Consumer Product Safety Commission (CPSC).

Learn more: Host controller interface (USB, Firewire)

Frequently Asked Questions

Q: What compressors are compatible with the 101N2156 / 101N2154 driver module?

A: This DC variable frequency compressor driver module is designed to work with direct-drive frequency compressors commonly used in portable refrigerators, camping coolers, and similar 12V/24V DC-powered refrigeration systems. Always verify your compressor's specifications match the driver's output requirements before installation.

Q: Can I use this module in a solar-powered refrigeration system?

A: Yes! The 12V and 24V DC input compatibility makes this driver module well-suited for solar-powered off-grid refrigeration setups. It works efficiently with battery banks and solar charge controllers that output in these voltage ranges.

Q: What is the difference between model 101N2156 and 101N2154?

A: Both models are DC direct frequency compressor driver modules with 12/24V compatibility, but they may differ in specific output parameters or connector configurations to suit different compressor units. Please refer to your compressor's documentation or contact us to confirm which model is the correct fit for your system.

Q: Is this suitable for a DIY mini fridge or cooling box project?

A: Absolutely. This module is categorized as an electrical DIY supply and is a popular choice for hobbyists and engineers building custom portable cooling units, mini fridges, or compact refrigeration enclosures powered by 12V or 24V DC sources.
