T-Shape Cabinet Hardware Jig | Aluminum Drill Positioning Template

Achieve Perfect Cabinet Handle Installations Every Time

The T-Shape Cabinet Hardware Jig is the ultimate precision drilling tool for woodworkers, remodelers, contractors, carpenters, and DIY enthusiasts. Whether you're upgrading a kitchen, renovating a bathroom, or installing a closet system, this aluminum alloy jig ensures perfectly aligned, professional-grade results — every single time.

Made in Mainland China.

Key Features

• Enhanced Drilling Precision: The T-shaped design eliminates skew and misalignment, ensuring accurate hole positioning for drawer pulls, cabinet handles, and door hardware.
• Streamlined Assembly: The 15-clip spacing design allows quick alignment and effortless marking across multiple handle groups, keeping your workflow fast and consistent.
• Multifunctional Design: Combines a T-shaped ruler and angle marking features into one tool — reducing the need to switch between multiple instruments during your project.
• Dependable Alignment Structure: The handle hole positioning system ensures accurate, repeatable marking for consistently neat handle and pull installations across all cabinet types.
• Accurate Angle Scaling: A clear angle scale supports precise angle measurement from 0–80mm, expanding this jig's usefulness for crafting, woodworking, and home improvement tasks.
• Durable Aluminum Alloy Construction: Lightweight yet robust, built to withstand regular workshop and job-site use.

Specifications

• Material: Aluminum Alloy
• Available Sizes: 400mm / 800mm
• Measurement Range: 0–80mm
• Long Ruler Thickness: ~8mm (0.31 in)
• Straight Ruler Thickness: ~14mm (0.55 in)
• Weight: 400mm – ~570g | 800mm – ~860g
• Packaging Size: ~41 × 7 × 6 cm (16.14 × 2.76 × 2.36 in)
• Certifications: RoHS, WEEE

Note: The 800mm version requires customer assembly of included accessories. Due to manual measurement, please allow 1–3cm size tolerance. Product color may slightly vary due to screen settings.

What's in the Box

• 1 × Cabinet Hardware Jig (T-Shape)

Who Is This For?

This drill guide jig is perfect for homeowners tackling DIY renovations, professional contractors and carpenters working on cabinetry installations, and remodelers who demand precision on every project. It's equally at home in residential kitchens, bathrooms, apartments, and professional woodworking shops.

Related Products You May Like

• 0.38mm Fine Nib Calligraphy Fountain Pen | Gold Trim Gift
• 1-Inch Round Dot Label Stickers – 500/Roll, 10 Colors

Expert Resource

For safety guidelines when using power tools and drilling equipment in the workplace or home, refer to the OSHA Power Tools Safety Guidelines.

Learn more: List of tools and equipment
