Water Level Switch Liquid Sensor Plastic Ball Vertical Float Arduino
Water Level Switch Liquid Sensor Plastic Ball Vertical Float Arduino
Couldn't load pickup availability
Discover the Water Level Switch Liquid Sensor Plastic Ball Vertical Float Arduino, a standout electronics accessories pick designed for dependable everyday performance and lasting value.
Specifications
Material: ABS
Product Description
SA float switch is a device used to sense the level of liquid within a tank. The switch may actuate a pump, an indicator, an alarm, or other device. It can be easily converted from normally open to normally close by inverting the float. Note: because the current that the switch can carry is much little(0.5A), you must use a relay or contactor when it is connected by a load, relay or contactor are not included here. Cable color may be different, we will random shipment. SA float switch is a device used to sense the level of liquid within a tank. The switch may actuate a pump, an indicator, an alarm, or other device.
It can be easily converted from normally open to normally close by inverting the float.
Note: because the current that the switch can carry is much little(0.5A), you must use a relay or contactor when it is connected by a load, relay or contactor are not included here.
Cable color may be different, we will random shipment.
Product Name : Water Level Sensor
Max Contact Rating : 10W
Max Switching Voltage : 100V DC/AC
Max Switching Current : 0.5A
Max Breakdown Voltage : 220V DC/AC
Max Carry Current : 1A
Max Contact Resistance : 100m ohm
Temperature Rating : -20 / +80 Celsuis
Float Ball Material : P.P
Float Body Material : P.P
Thread Dia(Approx) : 9.5mm / 0.374"
Switch Body Size : 23.3 x 57.7mm / 0.9" x 2.27"(Max D*H)
Cable Length : 36cm / 14.2"
Color : White
Package Content : 5 x Water Level Sensor
Note:Light shooting and different displays may cause the color of the item in the picture a little different from the real thing.The measurement allowed error is +/-1-3 cm.
Options
- Color: 5pcs
- Voltage: 0
Frequently Asked Questions
Q: What is the Water Level Switch Liquid Sensor Plastic Ball Vertical?
A: The Water Level Switch Liquid Sensor Plastic Ball Vertical is a quality electronics accessories pick. The switch may actuate a pump, an indicator, an alarm, or other device.
Q: What is the Water Level Switch Liquid Sensor Plastic Ball Vertical made of?
A: The Water Level Switch Liquid Sensor Plastic Ball Vertical is made from ABS Product Description SA float switch i, measuring 23.3 x 57.7mm / 0.9.
Q: Why choose the Water Level Switch Liquid Sensor Plastic Ball Vertical?
A: The Water Level Switch Liquid Sensor Plastic Ball Vertical stands out in our electronics accessories range — It can be easily converted from normally open to normally close by inverting the float.
